Home / forum / Lounges / Maya Basics & Newbie Lounge / Do anyone know how to create planet Earth shader with city lights in a "night" side?
Register FAQ Members List Calendar Mark Forums Read

New Thread

Thread Tools
Old 22-12-2003, 05:56 PM   #1
victstep
Registered User

victstep's Avatar

Join Date: Dec 2003
Posts: 10
Thanks: 0
Thanked 0 Times in 0 Posts
Default Do anyone know how to create planet Earth shader with city lights in a "night" side?

Hi!

I am ex-3dsmax user, and I am trying to create in Maya photorealistic planet Earth shader, with city lights in a "night" side of the planet. I'am mean 2 textures shader: one texture visible only in a "day" side of the shader and second texture visible ONLY (!!!) in a "nigh" side of the shader.

Just in 3dmax it's very simple: self-illumination->falloff->shadow/light; but in Maya... couple of weeks I can't find the answer to my question, and this is not a first Maya forum where I am asking to help.

Please if someone know a tutorial about it tell me, or gave me the right direction for my research.

P.S. Please, do not answer like "just use incandescence" (it's dosen't work); or "just use surfaceLuminance"; please explain HOW to use.

Thank you.
victstep is offline   Reply With Quote
Old 22-12-2003, 09:11 PM   #2
fredriksson
Subscriber

fredriksson's Avatar

Join Date: Jun 2003
Location: Sweden
Posts: 571
Thanks: 0
Thanked 1 Time in 1 Post
Default

Alright, this took me 1 min to set up, if you get the hang of the node based structure it isn't too hard.
Check out the image I prepared. The ramp is just a ramp with white-black range (you need to tweak it to your preference). The grid is where you put your file node (I didn't have a good one handy). You then multiply the ramps out-value with the files and you input that into the incandescence. Hope it helps. (the stucco is just for some color)

edit. You should perhaps clamp the surfaceLuminance, I don't know what valuerange it has, but it seems to work fine without.
Attached Thumbnails
Click image for larger version

Name:	test1.jpg
Views:	983
Size:	76.6 KB
ID:	12236
__________________
Björn 'santa' Fredriksson

<A href=http://www.bjornfredriksson.com>Site Online.</A>

Check out our 1on1on1 battle for the SandCrawlers.

Last edited by fredriksson : 22-12-2003 at 09:15 PM.
fredriksson is offline   Reply With Quote
Old 23-12-2003, 12:37 PM   #3
victstep
Registered User

victstep's Avatar

Join Date: Dec 2003
Posts: 10
Thanks: 0
Thanked 0 Times in 0 Posts
Default

Thank you!

It's work great!
Attached Thumbnails
Click image for larger version

Name:	earth.jpg
Views:	937
Size:	28.6 KB
ID:	12252
victstep is offline   Reply With Quote
Old 23-12-2003, 12:43 PM   #4
rich
Subscriber

rich's Avatar

Join Date: Oct 2003
Location: Paris, France
Posts: 418
Thanks: 0
Thanked 0 Times in 0 Posts
Default

I have a good Earth Shader that you can download from Simply Maya (see the link in my signature)

I didn't include the night map in the released ZIP file; but if you want to play with it, here it is....
Attached Thumbnails
Click image for larger version

Name:	earthmoonlit.jpg
Views:	950
Size:	56.4 KB
ID:	12253
__________________
That'll do donkey... that'll do...
rich is offline   Reply With Quote
Old 23-12-2003, 12:43 PM   #5
victstep
Registered User

victstep's Avatar

Join Date: Dec 2003
Posts: 10
Thanks: 0
Thanked 0 Times in 0 Posts
Default

Btw if you need a 2500x1250 Earth textures (free) you may visit: http://www.oera.net/How2/TextureMaps.htm

Thanks again.
victstep is offline   Reply With Quote
